Originally published in the 1940s, this book has given special attention to the fundamental principles that underlie the methods of sheet-metal pattern drafting, and discussed practical shop problems in sheet-metal drafting of the kind that occur in every day. In this way, the reader will be able to gain the practical viewpoint that comes to other mechanics only after many years of sheet-metal pattern work.
Please note: To study this book, proficiency in advanced mechanical drawing is necessary.
Contents Covered:
- Preface
- Introduction
- Elbows
- T Pipe Joints
- Cornices
- Radial-Line Developments
- Classification of Intersections
- Intersections of Frustums of Cones with Cylinders
- Development of Scalene Cones
- Triangulation Methods
- Methods of Design
- Horizontal Y Branches
- Clustered Y Branches
- Parallel-Line Methods (Advanced)
- Designing Transitional Elbows
- Airplane Sheet-Metal Drafting
- Skylights
- Definitions and Construction Methods
- Index
Format: | PDF Digital Reprint, e-Facsimile |
No. of Pages: | 195 |
Page Size: | A4 (210mm × 297mm) |
Download Size: | 57.3 MB |
